Name: PG-4001XR EOPN GOPN XPON ONU 4GE+POTS+2USB 2,4G&5,8G WlFl
Brand: Shenzhen Pioneergoods Communication CO.,Ltd
SKU: 00187
Availability: InStock
Rating: 5 (1 reviews)

Home > GPON ONU

PG-4001XR EOPN GOPN XPON ONU 4GE+POTS+2USB 2,4G&5,8G WlFl

Description Review

Description

PG-4001XR EOPN GOPN XPON ONU 4GE+POTS+2USB 2,4G&5,8G WlFl

Product Description:

PG-4001XR is designed as HGU (Home Gateway Unit) in different FTTH solutions. The carrier-class FTTH application provides data service access

PG-4001XR is based on mature and stable, cost-effective XPON technology. It could switch automatically into EPON mode or GPON mode when access to the EPON OLT and GPON OLT.

PG-4001XR adopts high reliability, easy management, configuration flexibility and good quality of service guarantees to meet the technical performance of EPON Standard of China Telecom CTC3.0 and GPON Standard of ITU-TG.984.X

Features :

Support EPON/GPON mode and switch mode automatically

Support Route mode for PPPoE/DHCP/Static IP and Bridge mode

Support IPv4 and IPv6 Dual mode

Support 2.4G&5.8G WIFI and Multiple SSID

Support IEEE 802.ax

Support SIP Protocol for VoIP Service

Support LAN IP and DHCP Server configura- tion

Support Port Mapping and Loop-Detect

Support Firewall function and ACL function

Support IGMP Snooping/Proxy multicast feature

Support TR069 remote configuration and maintenance

Specialized design for system breakdown prevention to maintain stable system

Specifications:

Technical item	Details
PON Interface	1 GPON BoB（ Bosa on Board） Receiving sensitivity: ≤-27dBm Transmitting optical power: 0~+5dBm Transmission distance: 20KM
Wavelength	TX: 1310nm, RX: 1490nm
Optical Interface	SC/UPC Connector
Chip Spec	ZX279128S DDR3 4Gbit
Flash	2Gbit SPI NAND Flash
LAN Interface	4 x 10/100/1000Mbps auto adaptive Ethernet interfaces. Full/Half, RJ45 connector
Wireless	Compliant with IEEE802.11b/g/n, ac ，ax 2.4G Operating frequency:2.400-2.4835GHz 5.8G Operating frequency:5.150-5.825GHz 2.4G 22 MIMO, rate up to 574Mbps 5.8G 22 MIMO, rate up to 1201Mbps 5 external antennas 5dBi Support Multiple SSID
VoIP Interface	FXS, RJ11 connector Support: G.711/G.723/G.726/G.729 codec Support: T.30/T.38/G.711 Fax mode, DTMF Relay Line testing according to GR-909
USB	Standard USB2.0 and USB3.0
LED	11 LED, For Status of WPS、 5G、WLAN、 FXS、 LAN1~LAN4、LINK、PON、 POWER
Push-Button	4 For Function of Factory Reset、 WPS、WiFi、 POWER
Operating Condition	Temperature: 0 ℃~+50 ℃ Humidity: 10% ～90%（ non-condensing）
Storing Condition	Temperature: -30℃~+60 ℃ Humidity: 10% ～90%（ non-condensing）
Power Supply	DC 12V/1.5A
Power Consumption	≤6W
Dimension	293mm×144mm×54mm（ L×W×H）
Net Weight	0.35Kg
Storing Condition	Temperature: -30℃~+60 ℃
